Eclipse Slimline Automatic Operation Hand Dryer in Designer Black

  • Drying time of less than 15 seconds
  • Adjustable temperature
  • This unit can be hard-wired by an electrician or used with the cord & plug provided
  • 5 Year Warranty Period (3 Years Parts and Labour + 2 Years Parts Only)

FINISH
Product Code
ML_ECLIPSE_DESIGNER
Dimensions
287.9mmH x 220mmW x 100mmD
Product available for collection through Met-Collect
Click here for details
Email to colleague Product enquiry
Product successfully added to Met-Schedule

This unit is accessible compliant when installed in accordance with AS1428.1. guidelines.

Notes

  • For Metlam Australia Care and Maintenance Guidelines, Installation Instructions, Product Specifications, and Warranty Details, please refer to the Downloads tab.

Product Enquiry

For more information, please complete the product enquiry form or contact Metlam Australia.

HEAD OFFICE

For Accounts, Customer Service, Sales & General Enquiries:
T: 1300 METLAM
    (1300 638 526)

INTERNATIONAL SALES

For Accounts, Customer Service, Sales & General Enquiries:
T: 1300 METLAM
   (1300 638 526)

NSW (Incorporating ACT)

For Sales & Customer Service Enquiries:
T: 02 8778 8801

QUEENSLAND

For Sales & Customer Service Enquiries:
 T: 07 3247 0200

VICTORIA (Incorporating TAS)

For Sales & Customer Service Enquiries:
T: 03 5420 8800

WESTERN AUSTRALIA

For Sales & Customer Service Enquiries:
T: 08 6250 2601

SOUTH AUSTRALIA & NORTHERN TERRITORY

For Sales & Customer Service Enquiries:
T: 0407 553 045
NEW ZEALAND

For Sales & Customer Service Enquiries:
T: 0407 863 730

Material 1.2mm #304 Satin Stainless Steel
Finish Designer Black Powder Coat
Warranty 5 Year Warranty (3 Years Parts and Labour + 2 Years Parts Only)
Power Use 220-240 Volts, 50Hz
Operating Sound Level 72db (+-3)@1M db
Motor Speed  Min. 16,000 RPM - Max. 29,000 RPM
Motor Speed Notes 250-500W Brush Type, Dual Ball Bearings, 95° auto reset overload
Air Speed  Min. 95m/s ==212MPH - Max. 115m/s ==257MPH
Motor Cut-Off Time 60-second power cut off, auto reset
Rated Power Min. 575 Watts - Max. 1000 Watts
Energy Per Day Min. 2.4 Watt-hours (Wh) - Max. 4.17 Watt-hours (Wh)
Sensor Type Infrared Automatic - 152mm +/- 20mm present blue LED indicates operation/range
Drying Time Less than 15 seconds
IP Rating IP24
DP Rating IPX 1
Heater Element 325-500W
Warm Air Speed: 95m/s - 115m/s (Adjustable). Temp: Ambient +30°
Case Security 2 SS theft-resistant hex drive screws (hex key supplied)
Net Weight 4.2kg
Notes
* Hardwire - 80mm from the connection point to the wall.
* Cord and Plug - 80mm from the connection point to the bottom of the unit.
