Eclipse Slimline Automatic Operation Hand Dryer in White

Drying time of less than 15 seconds
Adjustable temperature
This unit can be hard-wired by an electrician or used with the cord & plug provided
5 Year Warranty Period (3 Years Parts and Labour + 2 Years Parts Only)

FINISH

Product Code

ML_ECLIPSE01_WHT

Dimensions

287.9mmH x 220mmW x 100mmD

This unit is accessible compliant when installed in accordance with AS1428.1. guidelines.

For Metlam Australia Care and Maintenance Guidelines, Installation Instructions, Product Specifications, and Warranty Details, please refer to the Downloads tab.

CUSTOMER SERVICE & HEAD OFFICE OPERATIONS

HEAD OFFICE 17 Parkers Road New Gisborne VIC 3438 For Accounts, Customer Service, Sales & General Enquiries: Opening Hours: 8:30am - 5pm (AEST)	T: 1300 METLAM (1300 638 526) E: [email protected]
INTERNATIONAL SALES 17 Parkers Road New Gisborne VIC 3438 For Accounts, Customer Service, Sales & General Enquiries:	T: 1300 METLAM (1300 638 526) E: [email protected]
NSW (Incorporating ACT) Sydney Branch Unit 54, 3 Kelso Crescent Moorebank NSW 2170 For Sales & Customer Service Enquiries: Opening Hours: 8:30am - 5pm (AEST)	T: 02 8778 8801 E: [email protected] E: [email protected]
QUEENSLAND Brisbane Branch Shop 2, 57-59 Rosemount Terrace Windsor QLD 4030 For Sales Enquiries:	T: 07 3247 0200 E: [email protected]
VICTORIA (Incorporating TAS) Melbourne Branch 22 Gallivan Road New Gisborne VIC 3438 For Sales & Customer Service Enquiries:	T: 03 5420 8800 E: [email protected] E: [email protected]
WESTERN AUSTRALIA (Incorporating NT & SA) Perth Branch Unit 1, 5 Bramall Street East Perth WA 6004 For Sales & Customer Service Enquiries: Opening Hours: 8:30am - 5pm (AWST)	T: 08 6250 2601 E: [email protected] E: [email protected] E: [email protected]
NEW ZEALAND Head Office 17 Parkers Road New Gisborne VIC 3438 For Sales & Customer Service Enquiries:	T: 0407 863 730 E: [email protected]

Material	1.2mm #304 Satin Stainless Steel
Finish	White Powder Coat Steel
Features	Touch-free Patented high-flow dual air outlets
Warranty	5-Year Warranty (3 Years Parts and Labour+ 2 Years Parts Only)
Power Use	220-240 Volts, 50Hz
Operating Sound Level	72db (+-3)@1M db
Motor Speed	Min. 16,000 RPM - Max. 29,000 RPM
Motor Speed Notes	250-500W Brush Type, Dual Ball Bearings, 95° auto reset overload
Air Speed	Min. 95m/s ==212MPH - Max. 115m/s ==257MPH
Motor Cut-Off Time	60-second power cut off, auto reset
Rated Power	Min. 575 Watts - Max. 1000 Watts
Energy Per Day	Min. 2.4 Watt-hours (Wh) - Max. 4.17 Watt-hours (Wh)
Sensor Type	Infrared Automatic - 152mm +/- 20mm present blue LED indicates operation/range
Drying Time	Less than 15 seconds
IP Rating	IP24
DP Rating	IPX 1
Heater Element	325-500W
Warm Air	Speed: 95m/s - 115m/s (Adjustable). Temp: Ambient +30°
Case Security	2 SS theft-resistant hex drive screws (hex key supplied)
Net Weight	4.2kg
Notes	* Hardwire - 80mm from the connection point to the wall. * Cord and Plug - 80mm from the connection point to the bottom of the unit.
