206B206B Gravity Hinge Bolt Through in Satin Stainless Steel

Specification

Material #304 Stainless Steel
Nylon Inserts
Finish Satin Stainless Steel
Mounting Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges 35mm
Specify 206B_LHHO_SS: Left Hand, Hold Open. Assists door to move towards Hold Open position
206B_RHHO_SS: Right Hand, Hold Open. Assists door to move towards Hold Open position
Features Gravity-assisted door opening/door closing with lift-off capability.
Load Rating 15Kg per hinge


For optimum performance -
2 hinges per door up to 30Kgs
For doors over 30Kg allow for 15Kg per hinge

Note: 3 Hinges per door is recommended to prevent door bowing

  Note: All hinges are available with or without fixings.  Please nominate your requirements at the time of ordering.
Disclaimer Gravity hinges contain no mechanical components. The functionality of these hinges can vary depending on the environment.
When selecting this product, please view our Product Disclosure Statement in the Care and Maintenance Download below.



206B Gravity Hinge Bolt Through

SSS

Qty

Product successfully added to MetSpec

Downloads & Resources

Stainless Steel Cleaning & Maintenance
Accessibility and safety features of Metlam Australia Toilet Partition Hardware and how to use them
Troubleshooting your Metlam Australia Toilet Partition Hardware - Hinges

Product Enquiry

Please call Metlam or use the product inquiry form if you need more information.

CUSTOMER SERVICE & HEAD OFFICE OPERATIONS

HEAD OFFICE
17 Parkers Road
New Gisborne VIC 3438

For Accounts, Customer Service, Sales & General Enquiries:
Opening Hours: 8:30am - 5pm (AEST)


T: 1300 METLAM
   (1300 638 526)

INTERNATIONAL SALES
17 Parkers Road
New Gisborne VIC 3438

For Accounts, Customer Service, Sales & General Enquiries:


T: 1300 METLAM
   (1300 638 526)
NSW (Incorporating ACT)
Sydney Branch
Unit 54, 3 Kelso Crescent
Moorebank NSW 2170

For Sales & Customer Service Enquiries:
Opening Hours: 8:30am - 5pm (AEST)



T: 02 8778 8801

QUEENSLAND
Brisbane Branch
Shop 2, 57-59 Rosemount Terrace
Windsor QLD 4030

For Sales Enquiries:

T: 07 3247 0200
VICTORIA (Incorporating TAS)
Melbourne Branch
22 Gallivan Road
New Gisborne VIC 3438

For Sales & Customer Service Enquiries:



T: 03 5420 8800
WESTERN AUSTRALIA (Incorporating NT & SA)
Perth Branch
Unit 1, 5 Bramall Street
East Perth WA 6004

For Sales & Customer Service Enquiries:
Opening Hours: 8:30am - 5pm (AWST)



T: 08 6250 2601
NEW ZEALAND
Head Office
17 Parkers Road
New Gisborne VIC 3438

For Sales & Customer Service Enquiries:




T: 0407 863 730

Technical Specification


206B206B Gravity Hinge Bolt Through in Satin Stainless Steel

Specification

Material #304 Stainless Steel
Nylon Inserts
Finish Satin Stainless Steel
Mounting Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges 35mm
Specify 206B_LHHO_SS: Left Hand, Hold Open. Assists door to move towards Hold Open position
206B_RHHO_SS: Right Hand, Hold Open. Assists door to move towards Hold Open position
Features Gravity-assisted door opening/door closing with lift-off capability.
Load Rating 15Kg per hinge


For optimum performance -
2 hinges per door up to 30Kgs
For doors over 30Kg allow for 15Kg per hinge

Note: 3 Hinges per door is recommended to prevent door bowing

  Note: All hinges are available with or without fixings.  Please nominate your requirements at the time of ordering.
Disclaimer Gravity hinges contain no mechanical components. The functionality of these hinges can vary depending on the environment.
When selecting this product, please view our Product Disclosure Statement in the Care and Maintenance Download below.




Downloads & Resources



The photographs and line drawings of the products presented above are representational only.
