106B Gravity Hinge Bolt Through in Satin Chrome Plate

  • Diecast Zinc Alloy ZP3
  • #304 Grade Stainless Steel Shaft
  • Bolt Through
  • Liftoff Capability
  • Available in Hold Open or Hold Closed - Please Specify
  • Available in Left Hand or Right Hand - Please Specify

FINISH
Product Code
106B
Dimensions
80mmH x 82mmW x 16mmD
Email to colleague Product enquiry
Product successfully added to Met-Schedule

Notes

Please specify at the time of ordering

  • 106B_LHHC_SCP: Left Hand, Hold Closed - Assists the door to move towards a Hold Closed Position
  • 106B_LHHO_SCP: Left Hand, Hold Open - Assists the door to moved towards a Hold Open Position
  • 106B_RHHC_SCP: Right Hand, Hold Closed - Assists the door to move towards a Hold Closed Position
  • 106B_RHHO_SCP: Right Hand, Hold Open - Assists the door to move towards a Hold Open Position



  • For Metlam Australia Care and Maintenance Guidelines, Installation Instructions, Product Specifications, and Warranty Details, please refer to the Downloads Tab.

Disclaimer: Gravity Hinges contain no mechanical components.  The functionality of these hinges can vary depending on the environment.  When selecting this product, please view our Product Disclosure Statement in the Downloads Tab.

Product Enquiry

For more information, please complete the product enquiry form or contact Metlam Australia.

HEAD OFFICE

For Accounts, Customer Service, Sales & General Enquiries:
T: 1300 METLAM
    (1300 638 526)

INTERNATIONAL SALES

For Accounts, Customer Service, Sales & General Enquiries:
T: 1300 METLAM
   (1300 638 526)

NSW (Incorporating ACT)

For Sales & Customer Service Enquiries:
T: 02 8778 8801

QUEENSLAND

For Sales & Customer Service Enquiries:
 T: 07 3247 0200

VICTORIA (Incorporating TAS)

For Sales & Customer Service Enquiries:
T: 03 5420 8800

WESTERN AUSTRALIA

For Sales & Customer Service Enquiries:
T: 08 6250 2601

SOUTH AUSTRALIA & NORTHERN TERRITORY

For Sales & Customer Service Enquiries:
T: 0407 553 045
NEW ZEALAND

For Sales & Customer Service Enquiries:
T: 0407 863 730

Material Diecast Zinc, Alloy ZP3
#304 Grade Stainless Steel Shaft
Nylon Inserts
Finish
Satin Chrome Plate
Mounting
Bolt Through
Bolt Through Fixings Supplied (64mm Threads unless specified otherwise)
Features Gravity-assisted door opening/door closing with Lift-Off Capability
Minimum Hinge Clearance For Lift-Off Hinges
30mm
Load Rating
15Kg per hinge
For optimum performance -
2 hinges per door up to 30Kgs
For doors over 30Kg allow for 15Kg per hinge
Note: 3 Hinges per door is recommended to prevent door bowing
