MLR55TPH_PEENPull Down Peened Grab Rail with Toilet Roll Holder (SMR55P_TPH - Previous Code)

Specification

Material #304 Stainless Steel - 32mmØ
Peened Non-Slip Finish
Tubing 1.2mm #304 Stainless Steel - 32mmØ
Mounting Bracket
& Brace
4.5mm Formed #304 Stainless Steel
Toilet Roll Holder 12.5mmØ Stainless Steel Bar
Finish Satin Stainless Steel with a Peened Non-Slip Finish
Overall Dimensions 800mmD x 300mmH x 100mmW
Grab Rail 243.6mmH from outer edge to edge
Toilet Roll Holder 168mmL with top of holder 50mm below underside of upper rail
Mounting Bracket 100mmW x 300mmH x 30~50mmD x 4.5mmT
Mounting Concealed Fix - 80mmØ Mount
Mounting Holes 6
Features Click-lock system to prevent rail sliding down
Unit is Seamless Welded & Polished
Consumable Advice Standard Toilet Roll, can hold up to 230 sheets per roll
Also Available

MLR55_TPH_SS: Satin Stainless Steel

MLR55_TPH_PSS: Polished Stainless Steel

Notes

* It is the responsibility of the installer to ensure that the surface/substrate that the unit is installed upon and the fixings used are suitable to withstand the weight bearing loads of the unit and if required as per AS1428 / Australian building code regulations.

* Compliant with the Force Requirements within AS1428.1: 2021, Section 14.



MLR55TPH_PEEN
MLR55TPH_PEEN

PEENED

Qty

Product successfully added to MetSpec

Product Enquiry

Please call Metlam or use the product inquiry form if you need more information.

CUSTOMER SERVICE & HEAD OFFICE OPERATIONS

HEAD OFFICE
17 Parkers Road
New Gisborne VIC 3438

For Accounts, Customer Service, Sales & General Enquiries:
Opening Hours: 8:30am - 5pm (AEST)


T: 1300 METLAM
   (1300 638 526)

INTERNATIONAL SALES
17 Parkers Road
New Gisborne VIC 3438

For Accounts, Customer Service, Sales & General Enquiries:


T: 1300 METLAM
   (1300 638 526)
NSW (Incorporating ACT)
Sydney Branch
Unit 54, 3 Kelso Crescent
Moorebank NSW 2170

For Sales & Customer Service Enquiries:
Opening Hours: 8:30am - 5pm (AEST)



T: 02 8778 8801

QUEENSLAND
Brisbane Branch
Shop 2, 57-59 Rosemount Terrace
Windsor QLD 4030

For Sales Enquiries:

T: 07 3247 0200
VICTORIA (Incorporating TAS)
Melbourne Branch
22 Gallivan Road
New Gisborne VIC 3438

For Sales & Customer Service Enquiries:



T: 03 5420 8800
WESTERN AUSTRALIA (Incorporating NT & SA)
Perth Branch
Unit 1, 5 Bramall Street
East Perth WA 6004

For Sales & Customer Service Enquiries:
Opening Hours: 8:30am - 5pm (AWST)



T: 08 6250 2601
NEW ZEALAND
Head Office
17 Parkers Road
New Gisborne VIC 3438

For Sales & Customer Service Enquiries:




T: 0407 863 730

Technical Specification


MLR55TPH_PEENPull Down Peened Grab Rail with Toilet Roll Holder (SMR55P_TPH - Previous Code)

Specification

Material #304 Stainless Steel - 32mmØ
Peened Non-Slip Finish
Tubing 1.2mm #304 Stainless Steel - 32mmØ
Mounting Bracket
& Brace
4.5mm Formed #304 Stainless Steel
Toilet Roll Holder 12.5mmØ Stainless Steel Bar
Finish Satin Stainless Steel with a Peened Non-Slip Finish
Overall Dimensions 800mmD x 300mmH x 100mmW
Grab Rail 243.6mmH from outer edge to edge
Toilet Roll Holder 168mmL with top of holder 50mm below underside of upper rail
Mounting Bracket 100mmW x 300mmH x 30~50mmD x 4.5mmT
Mounting Concealed Fix - 80mmØ Mount
Mounting Holes 6
Features Click-lock system to prevent rail sliding down
Unit is Seamless Welded & Polished
Consumable Advice Standard Toilet Roll, can hold up to 230 sheets per roll
Also Available

MLR55_TPH_SS: Satin Stainless Steel

MLR55_TPH_PSS: Polished Stainless Steel

Notes

* It is the responsibility of the installer to ensure that the surface/substrate that the unit is installed upon and the fixings used are suitable to withstand the weight bearing loads of the unit and if required as per AS1428 / Australian building code regulations.

* Compliant with the Force Requirements within AS1428.1: 2021, Section 14.




Downloads & Resources



The photographs and line drawings of the products presented above are representational only.
